iTelescope - T32 - Wide Deep Field - Australia


< Previous Telescope  |  Next Telescope >



Location Information


Observatory: iTelescope.Net at Siding Spring Observatory Australia - MPC Q62

Telescope: 0.43-m f/6.8 reflector + CCD

Timezone:  UTC +10:00 New South Wales, Australia Daylight savings time is observed.

Minimum Target Elevation: Approx 35° EAST & NORTH, 45° WEST, 35° SOUTH


South 31° 16' 24" East 149° 03' 52"

Elevation: 1122m  MPC Code Q62


Operational Notes


T32 features a HUGE CCD chip with an amazing wide FoV. Matched up with the wonderful Planewave mount this telescope will deliver incredable data. Note: VERY large FITs files - 32Mb Binx1.  FITS and TIF file formats. Dark Frame calibration data is available for  60, 120, 180, 300 & 600 second exposures. Binx1 - Binx2.  Raw data can be found at data.itelescope.net.


  • ABG. Recommended Maximum Exposure 300 secs.
  • The Planewave Ascension 200HR mount is so accurate whilst tracking that iTelescope Admin have disabled active guidance, with a corresponding decrease in session setup time when imaging.


Instrument Package


CCD: Moravian G4 16000

QE: 60% Peak
Gain: 1.6 e-/ADU

Full Well:  ~100,000 e- (ABG)

Dark Current:  ~0.05 e-/pixel/sec. @ -15º C

Pixel Size:  9um Square

Resolution:  0.63 arcsec/pixel

Sensor: KAF-16803

Cooling: -15º C default

Array:   4096 x 4096 pixels

FOV:  43.2 x 43.2 arcmin

Filters:

Astrodon E-Series Luminance Red, Green, Blue

Astrodon 5nm Ha, SII, OIII

Astrodon Johnson/Couisins V, Ic

Position Angle: 90º



Telescope Optics


OTA: Planewave 17" CDK

Optical Design: Corrected Dall-Kirkham Astrograph

Aperture: 431mm

Focal Length: 2912mm

F/Ratio: f/6.8

Guiding: Active Guiding Disabled

Mount: Planewave Ascension 200HR



Telescope Horizon Limits


South: 18°

North: 18°

East: 18°

West: 38°





Transformation Coefficients



Thanks to Lew Cook for the information!
